SCISSOR LIFTS |
|||||||
|
MAKE |
GENIE |
GENIE |
GENIE |
GENIE |
GENIE |
GENIE |
GENIE |
|
MODEL |
GS2646 |
GS3246DC |
GS4069DC |
GS3268RT |
GS4069RT |
GS4390RT |
GS5390RT |
|
Working height |
9.92m |
11.75m |
14.2m |
11.75m |
14.02m |
14.5m/15m |
17.1m/18.15m |
|
Platform height |
7.92m |
9.75m |
12.2m |
9.75m |
12.02m |
12.5m/13.1m |
15.2m/16.15m |
|
Platform size deck extended |
1.10m x 3.8m |
1.15m x 3.18m |
1.6m x 3.71m |
1.52m x 3.96m |
1.65m x 3.96m |
1.83 x 6.57m |
1.88 x 7.27 m |
|
Safe working capacity |
454kg |
318kg |
363kg |
454kg |
363kg |
680kg |
680kg |
|
Stowed width x length |
1.17m x 2.41m |
1.7m x2.41m |
1.75m x 3.12m |
1.73 x 2.67m |
1.75 x 3.96m |
2.29m x 3.94m |
2.29m x 4.88m |
|
Stowed height: guardrails down |
1.68m |
1.80m |
2.08m |
1.83m |
2.08m |
2.25m |
2.47m |
|
Weight |
1.956kg |
2.364kg |
4.947kg |
3.632kg |
4.647kg |
6.31kg |
7,639kg |
|
Power supply |
Electric |
Electric |
Electric |
Diesel |
Diesel |
Diesel |
Diesel |
|
Gradeability % |
30% |
25% |
33% |
35% |
35% |
50% |
40% |
